Hydraulic Cylinder Parts Explained: Key Components and Functions

| | 196 Views
Hydraulic Cylinder Parts

Hydraulic cylinders happen to be fundamentally mechanical actuators. It provides linear force through a push in a single direction. You can find out countless applications and Functions of Hydraulic Cylinders. They are everywhere in vehicles and manufacturing facilities. It also includes industrial machinery and generators.

Hydraulic cylinders are superior modules of hydraulic installations. These are subject to increasingly higher and more precise requirements. Dynamic Hydrofab produces standard and customer-definite hydraulic cylinders both. For applications you can think of steering cylinders, cylinders for lock gates and cylinders for heavy weather conditions where road salt and ammonia occur. Dynamic Hydrofab team of experts assemble cylinders according to a modular concept, which allows to drastically shorten the production time. Dynamic Hydrofab cylinders are now used for innovative problem solutions within a large number of sectors. Read below on What Are the Parts of Hydraulic Cylinder in detail.

Comprehending the Hydraulic Cylinder Components

A few core Hydraulic Cylinder parts are there that make up a hydraulic cylinder. These are:

  • The piston
  • Cylinder barrel
  • Piston rod
  • Seals
  • End caps.

The cylinder barrel is a chamber. Here the piston happens to move and holds hydraulic fluid. The piston generally used to be a long metal cylinder which moved inside part of the cylindrical shaped metal barrel. The piston rod is connected to the piston and runs outside a barrel, where it interacts with the pistons. Seals are also important to ensure that no fluid is lost, while the end caps stabilize and hold everything together.

Material Hydraulic Cylinder Components

Hydraulic Cylinder Components are made using robust materials. These materials ensure that hydraulic forms last for a long time. The kind of aluminum or steel used in the construction. It varies from cylinder to cylinder. Typically, an aluminum or steel piston remains smooth and straight as it travels through the bore of its partner, the cylinder. The piston rod is typically made of chrome plated steel. It is subjected to the forces presented by that hard working piston. Seals are normally made of flexible rubber or plastic that can withstand very high pressures and temperatures. End caps are designed for strength to hold all apparatuses securely also. It can be stainless steel or plastic or aluminum.

Inside a Hydraulic Pressure Cylinder

The hydraulic cylinder contains a fluid, usually oil or water. As the piston is moved, this fluid is forced through small openings to move another piston rod. This methodical procedure allows the hydraulic cylinder to be centrifugal in performing its tasks. After the fluid leaves one side of a cylinder and exits, it goes back to the reservoir from which it can be sucked again when necessary. The action causes the hydraulic cylinder to work and this fluid cycle will be continuous.

Hydraulic Cylinder for Lifting Tables

Your lifting table will be as good as new with the hydraulic cylinder for lifting tables. The hydraulic cylinders remain a replacement part for lifting tables. Our models are suitable for lifting between 450 and 700 kg. The force is exerted by means of hydraulic fluid, the force of the fluid ensures that the lifting table rises because the hinges are pushed further apart. From now on, you no longer have to purchase new motorcycle lifting tables, but only a new hydraulic cylinder.

Hydraulic Cylinder for a Workshop Press

A workshop press also uses a hydraulic cylinder to transfer force. These hydraulic cylinders have a connection for a compressor, mounting holes with thread and it is also possible to attach a pressure gauge to the cylinder.

Dynamic Hydrofab have hydraulic cylinders for workshop presses from 30 to 50 tons. Pressing is no problem for these cylinders. They are ideal as a replacement part or to use in your own project.
